For Cemented Carbide and Hard Brittle Mateirals
UDC Series, UPD Series

Introduction of UDCBH

Milling VM-40 (90HRA) grade tungsten carbide at ultra high speed!

UDCLB/UDCLBF
Direct milling on Carbide Bevel Gear

Optimized cutting parameters for Low-hardness carbides has greatly reduced the cycle time and milling cost!

Introduction of UDC Series

High Efficient Milling on Cemented Carbide and Hard Brittle (Non-Metallic) Materials! Tool Line Up: Ball, Long Neck Ball, Long Neck Radius End Mills / Drills / Thread Mills

UDCBF
Indexable Insert Mold Milling

The chip pocket designed on tool tip and sharp cutting edge with special treatment offer excellent surface finish.

UDCMX・UDCT
UDCMX+UDCT 16 holes Milling

"Direct Thread Milling" on Cemented Carbide.

UDCMX
ø2.5 100 holes Milling

Drilling Carbide - Stunning!

UDCLRS
Side milling using a radius tool

Side milling of cemented carbide with a long neck radius end mill with UDC coating!
The finished surface roughness of the bottom is a mirror finish with Ra10nm!

UDCRRS
Cemented Carbide VM-40(90HRA) Milling example of punching die

UDCRRS 6 flute long neck radius for roughing Multi-flutes with a 40゚ helix angle help to reduce cutting load. Milling efficiency and material removal volume greatly exceeds the conventional tool.

UDCLBH/UDCLRSF
Connector mold Cemented carbide F10 Milling Example

For roughing, the UDC-H series for high-efficiency machining reduces cycle time! For semi-finishing/finishing, the UDC-F series for high quality milling surface achieves a surface roughness of Ra 0.005µm!
